PL5066NL

SMT Flyback Transformer

For Tape & Reel packaging, add “T” suffix at the end of the part number: i.e. PL5066NLT.

Note: not all products have a Tape and Reel option. Please check datasheet for availability.

Dimensions 12.7 × 12 × 6.3 mm
Mounting

SMT

Construction Type

SMT Toroid

Turns Ratio

10

Inductance (µH)

35

Leakage Inductance MAX (μH)

8

DCR MAX (mΩ) Primary

150%

DCR MAX (mΩ) Secondary

45.5

DWV (Vrms)

2000

Moisture Sensitivity Level

1

Operating Temperature

-55°C to +125°C

Storage Temperature

-55°C to +125°C

Finish

Sn100

Packaging

Bulk

RoHS Compliant

Yes

Qualified Products List

No

The PL5066NL SMT Flyback Transformer is a robust component designed for efficient power conversion in a compact SMT Toroid construction, offering reliable performance across a wide operating temperature range of -55°C to +125°C. Its specifications, including a 10 turns ratio, 35 µH inductance, and 2000 Vrms DWV, ensure stable operation and effective power management for various applications.

NOTE: Data/Specifications are subject to change without notice.
