| Dimensions | 9.02 × 8.64 × 7.62 mm |
|---|---|
| Mounting | SMT |
| Construction Type | SMT Toroid |
| Turns Ratio | 0.4 |
| Isolation Voltage | 1500 |
| DCR MAX (mΩ) Primary | 910 |
| DCR MAX (mΩ) Secondary | 380 |
| Primary Inductance (µH) | 1200 |
| Leakage Inductance MAX (μH) | 910 |
| Voltage-time Product (V*uSec) | 27.2 |
| Operating Frequency (MHz) | 50kHz – 600kHz |
| Moisture Sensitivity Level | 3 |
| Operating Temperature | -40°C to +130°C |
| Storage Temperature | -40°C to +130°C |
| Finish | Tin/Lead (Sn63/Pb37) |
| Packaging | Bulk |
| RoHS Compliant | No |
| Qualified Products List | No |
| Height (mm) | 7.62 |
