| Dimensions | 23.37 × 21.6 × 8.6 mm |
|---|---|
| Mounting | SMT |
| Construction Type | SMT ER19 PLANAR |
| Turns Ratio | 4TPri:5TPri:1TSec:1TSec |
| DCR MAX (mΩ) Primary | 17.5 |
| DCR MAX (mΩ) Secondary | 20 |
| Primary Inductance (µH) | 194 |
| Rated Power (W) | 140 |
| Isolation Voltage | 1750 |
| Frequency Range (MHz) | 200kHz – 700kHz |
| Moisture Sensitivity Level | 1 |
| Operating Temperature | -40°C to +125°C |
| Finish | Tin/Lead (Sn63/Pb37) |
| Packaging | Bulk |
| RoHS Compliant | No |
| Features | High Frequency |
