| Dimensions | 29.46 × 25.4 × 9.1 mm |
|---|---|
| Mounting | SMT |
| Turns Ratio | 5TPri:5TPri:1TSec:1TSec |
| DCR MAX (mΩ) Primary | 15 |
| DCR MAX (mΩ) Secondary | 1.12 |
| Primary Inductance (µH) | 85 |
| Leakage Inductance MAX (μH) | 0.3 |
| Rated Power (W) | 250 |
| Frequency Range (MHz) | 200kHz – 700kHz |
| Operating Temperature | -40°C to +125°C |
| Finish | Sn100 |
| Packaging | Bulk |
| RoHS Compliant | Yes |
| Grade | Industrial |
| Features | High Frequency |
