| Dimensions | 29.46 × 26.67 × 10.4 mm |
|---|---|
| Mounting | SMT |
| Turns Ratio | 4TPri:4TPri:4TSec |
| DCR MAX (mΩ) Primary | 6.8 |
| DCR MAX (mΩ) Secondary | 4.5 |
| Primary Inductance (µH) | 211 |
| Leakage Inductance MAX (μH) | 0.3 |
| Rated Power (W) | 300 |
| Frequency Range (MHz) | 200kHz – 700kHz |
| Moisture Sensitivity Level | 1 |
| Operating Temperature | -40°C to +125°C |
| Finish | Sn100 |
| Packaging | Bulk |
| RoHS Compliant | Yes |
| Grade | Industrial |
| Features | High Frequency |
