| Dimensions | 16.5 × 10 × 5.3 mm |
|---|---|
| Mounting | SMT |
| Number of Channels | Single |
| Turns Ratio | 1CT:1CT |
| Inductance MIN (µH) | 150 |
| Inductance MAX (µH) | 450 |
| Insertion Loss MAX (dB) | 0.3 |
| Return Loss (dB) | 20 |
| DWV (VDC) | 4300 |
| Insulation | Basic |
| Creepage Distance MIN (mm) | 10 |
| Include CMC? | Yes |
| Operating Temperature | -40°C to +125°C |
| Finish | Sn100 |
| Moisture Sensitivity Level | 1 |
| RoHS Compliant | Yes |
| Packaging | T&R |
| Grade | Automotive |
| PoE Rating | N/A |
| Features | AEC-Q200 Compliance |
| Applications | Automotive |
