| Dimensions | 6.73 × 5.84 × 5.46 mm |
|---|---|
| Mounting | SMT |
| Turns Ratio | 1CT:1CT |
| Number of Channels | Single |
| Data Rate (Mbps) | 1062 |
| Primary Inductance (µH) | 3.75 |
| Rise Time MAX (nSec) | 280 |
| DCR MAX (mΩ) | 0.2 |
| HiPot (VRMS) | 1500 |
| Insertion Loss MAX (dB) | 2 |
| Application Bit Rate (Mbaud) | 1062.5 |
| Moisture Sensitivity Level | 3 |
| RoHS Compliant | No |
| Operating Temperature | -55°C to +125°C |
| Packaging | T&R |
