| Dimensions | 16 × 16 × 3.94 mm |
|---|---|
| Mounting | SMT |
| Number of Channels | Dual |
| Terminals | 1-3:4-8 / 1-3:5-7 |
| Turns Ratio | 1CT:3CT / 1CT:2.15CT |
| DCR MAX (mΩ) | 800, 3500 |
| Impedance (Ω) | 4000 |
| Droop MAX | 20% |
| Overshoot (V) | ±1V MAX |
| CMR MIN (dB) | 45 |
| Operating Frequency (MHz) | 75 kHz to 1 MHz |
| IR MIN (MΩ) | 10000 |
| IR @ | 250 Vdc |
| DWV (Vrms) | 100 |
| Operating Temperature | -55°C to +125°C |
| Storage Temperature | -55°C to +125°C |
| MAX Reflow Temperature (℃) | 225 |
| Moisture Sensitivity Level | 3 |
| Finish | Sn100 |
| Packaging | Bulk |
| Grade | COTS |
| Qualified Products List | No |
| RoHS Compliant | Yes |
