| Weight | 5 g |
|---|---|
| Dimensions | 15.86 × 15.86 × 6.35 mm |
| Mounting | THT |
| Number of Channels | Single |
| Terminals | 1-3:4-8 / 1:3:5-7 |
| Turns Ratio | 1CT: 1CT / 1CT: 0.707CT |
| DCR MAX (mΩ) | 3 |
| Impedance (Ω) | 4000 |
| Droop MAX | 20% |
| Overshoot (V) | ±1V MAX |
| CMR MIN (dB) | 45 |
| Operating Frequency (MHz) | 75 kHz to 1 MHz |
| IR MIN (MΩ) | 10000 |
| IR @ | 250 Vdc |
| DWV (Vrms) | 100 |
| Package | G |
| Operating Temperature | -55°C to +130°C |
| Storage Temperature | -55°C to +130°C |
| Moisture Sensitivity Level | 1 |
| Finish | Tin/Lead (Sn63/Pb37) |
| Packaging | Bulk |
| Grade | QPL |
| Qualified Products List | Yes |
| RoHS Compliant | No |
