Weight | 5 g |
---|---|
Dimensions | 16 × 16 × 8.64 mm |
Mounting | SMT |
Number of Channels | Dual |
Terminals | 1-3:4-8 / 11-13:14-18 ; 1-3:5-7 / 11-13:15-17 |
Turns Ratio | 1.0CT: 2.12CT / 1.0CT: 1.5CT |
DCR MAX (mΩ) | 1, 3.5 |
Impedance (Ω) | 4000 |
Droop MAX | 20% |
Overshoot (V) | ±1V MAX |
CMR MIN (dB) | 45 |
Operating Frequency (MHz) | 75 kHz to 1 MHz |
IR MIN (MΩ) | 10000 |
IR @ | 250 Vdc |
DWV (Vrms) | 100 |
Package | Flat Pack |
Operating Temperature | -40°C to +85°C |
Moisture Sensitivity Level | 3 |
Finish | Tin/Lead (Sn63/Pb37) |
Packaging | Bulk |
Grade | COTS |
Qualified Products List | No |
RoHS Compliant | No |
